23
1200 Series SmartPanels 1.0 User Manual
01-000HB03EG-A10
4 Appendix
4.1
Technical Specifications
Front Elements
32× software-assignable lever keys
2× rotary encoders for data entry
3× high-resolution, bright color, sunlight readable TFT Displays with multi-
touch control (capacitive)
1× threaded 6.3 mm jack for microphone
1× internal panel microphone
User-exchangeable Headset connector with preinstalled 4-pin male XLR
connector
2× full-range, high-quality speakers
1× USB 2.0 (standard Type-A, max. 1000 mA)
Technology RFID, Frequency 13.56 MHz (future use)
Frequency DTS Band 2400 ... 2483.5 MHz (future use)
Adaptation of the display brightness to the environment (future use)
Rear Elements
2× Ethernet ETH 3 / ETH 4 (Ethernet, AES67)
1× USB 2.0 (standard Type-C, max. 1000 mA)
1× MicroSD / MicroSDHC card up to 32 GB (for service purpose only)
2× Ethernet ETH 1 / ETH 2 (10/100/1000BASE-T Ethernet, AES67)
1× Expansion EXP connector for expansion panels
1× Management MNG connector for panel configuration
(separation of audio and management network, future use)
1× Matrix connector for matrix connection (AES3)
2× Analog audio 4-wire inputs and outputs
2× Headset (“Headset A” is identical to front connector signal)
1× Matrix connector for matrix connection (AES3)
3× GPI output, U
max
48 V / 300 mA, protected by self-healing fuse
3× GPI input, U
in
= +5 V ... +48 V
Overall
100 - 240 VAC, 50 - 60 Hz
483 mm / 19" (445 mm / 17.5", installing
dimensions)
20 % ... 90 % relative (non-condensing)
