Programmable Relay User Manual for ELC, EXM and PR Series 133 2020 v6.0 © Rievtech Co.,
Ltd. www.rievtech.com
need to connect an additional analogue amplifier block
between the analogue output of the special function and
the real analogue output. Using this amplifier, you
standardize the output range of the special function to a
value range of 0 to 1000.
PI Controller
Description of function
It is for proportional-action and integral-action controllers.
You can use both types of controller individually or
combined.
Connection
Description
Input A/M
Set the mode of the controller:
1: automatic mode
0: manual mode
Input R ( )
Use the input R to reset the output
AQ. As long as this input is set, the
input A/M is disabled. The output
AQ is set to 0.
Input PV
Analogue value: process value,
Influences the Output
Parameter
Sensor: Type of sensor being used
Min.: Minimum value for PV
value range: -10,000 to +20,000
Max.: Maximum value for PV
value range: -10,000 to +20,000
A: Gain
Value range: +- 10.00
B: Offset
Value range: +- 10,000
SP: Set-value assignment
value range: -10,000 to +20,000
Mq: Value from AQ with manual
mode.
Value range: 0 to 1,000
Parameter sets: application-related
pre-sets for KC, TI and Dir (see
below)
KC: Gain
value range: 00.00 to 99.99
TI: Integral time
value range 00:01 min to 99:59 min
Dir: Action direction of the
controller
value range: + or -
p: Number of decimal places
value range: 0, 1, 2, 3
Output AQ
Analog output (manipulated
variable)
Value range for AQ: 0 to 1,000
