Expansion Modules
Table 8 - Expansion Modules for PR-14, PR-18, PR-23, PR-24, PR-26 and Remote PLC CPUs (Max. 16 Units)
Model
Supply
Inputs
Outputs
PR-E-16AC-R
110-240 VAC/DC
8 Digital
4 Relays (10A) + 4 Relays (3A)
PR-E-16DC-DA-R
12-24 VDC
8Digital (4DA 0-10V)
4 Relays (10A) + 4 Relays (3A)
PR-E-16DC-DA-TN
12-24 VDC
8Digital (4DA 0-10V)
8 Transistor (0.3A)
PR-E-DC-16IN
12-24 VDC
16Digital (4DA 0-10V)
-
PR-E-DC-16DO
12-24 VDC
-
15 Relays (3A) + 1 Relays (10A)
PR-E-AI-I
12-24 VDC
4x0/4-20mA
-
PR-E-PT100
12-24 VDC
3 x Thermistor PT100
-
PR-E-AQ-VI
12-24 VDC
-
2 x 0-10 V/0-20 mA
PR-RS485
12-24 VDC
Additional Isolated RS485 Port
Table 9 - Expansion Modules for EXM PLC CPUs (Max. 8 Units)
Model
Supply
Inputs
Outputs
EXM-E-8AC-R
110-240 VAC/DC
4 Digital
2 Relays (10A) + 2 Relays (3A)
EXM-E-8DC-DA-R
12-24 VDC
4Digital (4DA 0-10V)
2 Relays (10A) + 2 Relays (3A)
EXM-E-AI-I
12-24 VDC
4 x 0/4-20mA
-
EXM-E-PT100
12-24 VDC
2 x Thermistor PT100
-
EXM-E-AQ-V
12-24 VDC
-
2 x 0-10 V
EXM-E-AQ-I
12-24 VDC
-
2 x 0-20 mA
EXM-E-RS485
12-24 VDC
Additional Isolated RS485 Port
Accessories
Table 10 - xLogic Accessories
Model
Description
ELC-RS232
RS232 Programming and communication lead between CPU and PC
ELC-USB
USB Programming lead between CPU and PC. Needed for firmware updates.
ELC-COPIER
A device used to copy a program from one CPU to another same model CPU
ELC-MEMORY
Real-time data logging module, which can log IO and program data with time and date stamp
PRO-RS485
Optically isolated RS232 to RS485 converter cable
ELC-BATTERY
A standard number of days for RTC retentivity is 20-days. This unit extends that to 1-year.
PR-FLAT
Expansion PR-E Ribbon Cable 1-metre
