The EXM CPU’s above will work as Clients (Masters) and the PCs will work as Servers (Slaves) in this example.
The SIM cards installed in each of the EXM CPUs will be assigned IP addresses dynamically by the mobile SIM provider each
time they establish a connection to the mobile network.
NOTICE:
The router in this example MUST have a fixed Internet IP address, which would be provided by the Internet
Service Provider (ISP) used.
In our diagram example above, we will use Computer1 and EXM1 as examples in how to communicate between them using
GPRS. The following configurations are applied to each device:
Computer1
o IP Address: 192.168.0.100
o Subnet Mask: 255.255.255.0
o Gateway: 192.168.0.1
Router
o LAN IP address: 192.168.0.1
