Figure 32 LCD Menu Structure
After being powered on, the CPU will check to see if a
valid program is stored within it.
If the program is accurate, then the CPU will be running,
meanwhile, the system cover will show as follows, this can
be customised within xLogicsoft, this is the default
initialization screen.
If there are several parameter pages, users can press
or keys to go to the page they require. The last page
is the cursor mode:
Cursor keys can be controlled in this page by pressing
arrow keys and ESC key at the same time.
