Marker Trace
Auto, Trace1
Auto, Trace1
--
Marker Freq
2.25 GHz
2.25 GHz
15.9730 ms
Marker Readout
Frequency
Frequency
--
Readout Auto
On
On
--
Line State
Off
Off
Off
Couple Markers
Off
Off
Off
Marker Table
Off
Off
Off
Peak
Cont Peak
Off
Off
Pk-Pk Search
Maximum Value
Maximum Value
Peak Threshold
On, -90 dBm
On, -90 dBm
Peak Excursion
On, 6 dB
On, 6 dB
Threshold Line
Off
Off
Peak Table
Off
Off
Peak Table Sort
Amplitude
Frequency
Table Readout
All
All
Marker Func
N dB Bandwidth
Off, -3.01 dB
Off, -3.01 dB
--
Band Function
Off
Off
Off
Marker Counter
Off
--
--
Gate Time
On, 100 ms
--
--
System
[3]
Power On
Preset
Preset
Preset Type
Default
Default
Align Auto
Off
Off
LAN Setting Mode
Manual
Manual
Display Line
Off, -25 dBm
Off, -25 dBm
Graticule
On
On
HDMI
Off
Off
HDMI Resolution
1280*720 60Hz
1280*720 60Hz
LCD
On
On
LCD Backlight
100%
100%
Power Switch
Default
Default
Beep Switch
Off
Off
User key
Off
Off
Language
English
English
Note
[1]
: This function is only available for RSA3045-TG/RSA3030-TG working in GPSA mode.
Note
[2]
: This function is only available for RSA3000 installed with the corresponding option.
Note
[3]
: Not affected by Preset settings.
