Rigol RSA5065N-OCXO Performance Verification Guide

RIGOL Chapter 2 Performance Verification Test
2-6 RSA3000 Performance Verification Guide
Test Record Form
Output Frequency of
Signal Generator
Offset
Measurement
Result
Limit
Pass/Fail
500 MHz
10 kHz offset
<-100 dBc/Hz, <-102 dBc/Hz (typical)
Absolute Amplitude Accuracy Test
Specification
Absolute Amplitude Accuracy
f
c
= 50 MHz, peak detector, PA off, attenuation = 10 dB, input signal level = -10 dBm, 20℃ to 30℃
Uncertainty
<0.3 dB
Test Devices
1. Signal Generator × 1
2. Power Meter × 1
3. Power Sensor × 1
4. Power Meter Connecting Cable × 1
5. Dual-N Cable × 1
6. Dual-BNC Cable × 1
