RIGOL Chapter 2 Functions of the Front Panel
2-4 VNA User Guide
Stop Freq
Sets the stop frequency of the current frequency channel.
Remarks:
When you modify the stop frequency, the center frequency and start frequency will
be modified automatically if the span remains to be unchanged.
Table 2-4 Stop Frequency
Parameter
Remarks
Default
Fmax
Range
(100 kHz + 10 Hz) to Fmax
Unit
GHz, MHz, kHz, Hz
Knob Step
step = span/200, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
CF step
CF Step
Changes the step size for the center frequency. Changing the center frequency by a
constant step-size value switches the channel to be measured continuously.
Remarks:
Set a proper CF step value, and then select the center frequency. Use the Up/Down
arrow key to switch the measurement channel at a fixed step size. Thus, the
instrument can sweep the adjacent channels manually.
Table 2-5 CF Step
Parameter
Remarks
Default
Fspan/10
Range
-Fmax to Fmax
Unit
GHz, MHz, kHz, Hz
Knob Step
step = span/200, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-2-5 step
CF Step Mode
The CF step mode consists of "Manual" and "Auto". By default, it is Auto.
