RIGOL Chapter 2 Functions of the Front Panel
2-12 VNA User Guide
Table 2-12 Sweep Time
Parameter
Remarks
Default
S11/S21: 1.05946 s
DTF: 1.48760s
Range
1 ms to 4,000 s
Unit
s, ms, us, ns, ps
Knob Step
sweep time/100, Min = 1 us
Left/Right Arrow Key Step
Up/Down Arrow Key Step
sweep time/10, Min = 10 us
Sweep Time Mode
Sets the "Sweep Time" to be "Auto" or "Manual". By default, it is "Auto".
Continue
Sets the current sweep mode to Continuous.
In continuous sweep mode, the system will go to the next sweep after each sweep is
completed.
Single
Sets the current sweep mode to Single.
Remarks:
⚫ When the system is in Continuous sweep mode, you need to press this key to
enter the single sweep mode and perform one measurement.
⚫ When the system is in Single sweep mode, only when you press Single or tap
Single again, can you launch the sweep process.
