Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-17
12. Log Mag(DTF)
Time-domain log magnitude display format in DTF.
13. Lin Mag(DTF)
Time-domain linear magnitude display format in DTF.
14. Return Loss(DTF)
Return loss in DTF.
Math Function
After performing Data->Memory operation, you can perform the calculation
between measurement data and memory trace.
⚫ Data/Memory
Measurement data divided by data in the memory trace.
⚫ Data*Memory
Measurement data multiplied by data in the memory trace.
⚫ Data - Memory
Measurement data subtracted by data in the memory trace.
⚫ Data + Memory
Measurement data added data in the memory trace.
⚫ Off
Disables the math function.
Note: The trace math functions are mutually exclusive. If you apply one math
operation to a certain trace, the last selected math operation function should be
disabled.
The math operation function is disabled when the trace format is "Log Mag(DTF)" or
"Lin Mag(DTF)".
Window Layout
Sets the window layout for the trace.
⚫ By default, it is Four Window for S11. The window layout function is available.
⚫ By default, it is UD Window for S21. The window layout function is available.
⚫ By default, it is UD Window for DTF. The window layout function is grayed out
and unavailable.
The available window layout includes:
⚫ Single Window
⚫ LR Window
⚫ UD Window
