Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-21
Table 2-16 Trigger Hold-off Time
Parameter
Remarks
Default
100 ms
Range
0 μs to 500 ms
Unit
s, ms, μs, ns, ps
Knob Step
trigger holdoff time/100, Min = 1 μs
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
Auto Trig State
Enables or disables the auto trigger function. By default, it is disabled.
Auto Trig
Sets the time that the instrument will wait for the trigger conditions to be met. When
the set waiting time times out, the instrument will not wait and start to initiate the
sweep measurement.
Table 2-17 Auto Trigger Time
Parameter
Remarks
Default
100 ms
Range
1 ms to 100 s
Unit
s, ms, μs, ns, ps
Knob Step
auto trigger time/100, Min = 1 μs
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
The relationship among the relevant parameters concerning trigger is shown in the
following figure.
