RIGOL Chapter 2 Functions of the Front Panel
2-32 VNA User Guide
The relationship between port delay and port length is correlative, as shown in the
following formula:
Port Length = Port Delay * Velocity of Light * Velocity Factor
Table 2-30 Port 1 Delay
Parameter
Remarks
Default
0.00 us
Range
-10.00 s to 10.00 s
Unit
s, ms, us, ns, ps, fs
Knob Step
Port 1 delay/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 1 delay/10
Unit
Sets the length unit for port extension: meter or feet. The default unit is meter.
Remarks:
When the unit is changed, the lengths of Port 1 and Port 2 should be changed along
with the unit conversion.
Port 1 Length
Sets the extension length for Port 1.
Table 2-31 Port 1 Length (m)
Parameter
Remarks
Default
0.00 m
Range
-3.00 Gm to 3.00 Gm
Unit
Meter (m, dm, cm)
Knob Step
Port 1 length/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 1 length/50
Table 2-32 Port 1 Length (ft)
Parameter
Remarks
Default
0.00 m
Range
- 32291731348.30 ft to
32291731348.30 ft
Unit
ft
Knob Step
Port 1 length/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 1 length/50
