RIGOL Chapter 2 Functions of the Front Panel
2-48 VNA User Guide
Offset Length
14.89 mm
C0
-2.71 fF
C1
2.478 fF/GHz
C2
-1.97e-1 fF/GHz
2
C3
-2.09e-2 fF/GHz
3
Meas Setup（DTF）
Avg Number
100
Ref Value
0.00 dBm
Port Extension
Off
Port Delay
1.00 as
Unit
meter
Port Length
0.00 cm
Port 1 Velocity
Factor
1
Port 1 Specific Loss
0.00 dB/m
Cal Kits
CK106A
Cal Type
Open
Offset Length
14.89 mm
C0
-2.71 fF
C1
2.478 fF/GHz
C2
-1.97e-1 fF/GHz
2
C3
-2.09e-2 fF/GHz
3
Stop Distance
4.62 m
Velocity Factor
0.66
Cable Loss
0.00 dB/m
FFT Window
Rectangular
Marker
Selected Marker
Marker 1
Marker Type
Position
Reference Marker
Marker 2
Marker Frequency
Fmax/2
Marker Distance
2.31 m
Line State
Off
Marker Table
Off
Peak
Cont Peak
Off
System
[1]
Power On
Preset
Preset Type
Default
LAN Setting Mode
DHCP
mDNS
Off
DNS
Manual
HDMI Output
Off
HDMI Resolution
1280*720 60Hz
