Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000 User Guide 2-25
trigger signal
triggers on the rising edge
trigger delay
trigger occurs
trig holdoff
auto trig
… …
… …
trigger occurs
trigger delay
sweep
measurem ent1
sweep
measurem ent2
(turn off trigger delay)
trigger occurs trigger occurs
… …
Figure 2-4 Trigger Parameter Relationship
