Backbox
Backbox Cover
Mounting Screws
Backbox Mounting Screws
Spotlight Cam
Security
Screw
Status Light &
Motion Sensors
White Wire
(unused, cap
with wire clip)
Backbox Cover
How it All Fits Together
Brown/Live
Wire
Earth
Wire
Blue/Neutral
Wire
76
