OPERATING YOUR RITELLO (R2 series)
A. PRESS ON THE PEDAL TO REMOVE THE UNIT
B. ATTACH THE MAIN UNIT ON THE DOLLY
Place the unit on its wheel base (dolly) by tipping front end slightly upward so
that the lip at the rear of the unit slips under the lip at the back, then drop the front
end downwards to lock.
A. TO REMOVE THE UNIT OFF THE WATER BASIN, UNLOCK BY TURNING THE LATCHES
B. ATTACHING MAIN BODY ON THE WATER BASIN
Place the main body over the water basin by aligning the Air-Inlet of both.
Then, lock the latches of both sides to secure proper installation.
THE MAIN UNIT WILL NOT OPERATE WITHOUT THE WATER BASIN PROPERLY
CONNECTED TO THE MAIN UNIT.
FILLING THE WATER BASIN
Fill the basin with cool water up to the min/max level indicated on the basin. Never
fill water above the Max-level line. When the water becomes thick with lint and dirt,
empty the water basin and refill with clean water. Add 2 capfuls of Ritello perfumes
to enjoy a nice ambient odor while cleaning.
CONNECT ELECTRICAL CORD TO WALL OUTLET
a. Pull the power cord out of its slot and plug into the wall outlet while making sure
that it matches the voltage rating. Press the (I) button to turn the unit ON then (+)
button to increase the speed or (-) to decrease. Using the display screen you may
choose the speed needed for the desired task.
b. To retract the cord, pull it gently towards you while holding the Plug-end to avoid
knocking things over.
ATTACHING/REMOVING THE HOSE
Insert the hose into the Air-Inlet until it clicks. Make sure to check the locking by
pulling the hose slightly. To remove, press on both clips and pull hose from machine.
p5
• DO NOT operate your machine without
water.
• Make sure you respect the water level
as indicated on the water pan.
• DO NOT OVERFILL
1
2
3
4
5
A
B
A
B
