NOTE: Always choose a level area when folding unit either into or from transport position.
NOTE: Lubricate all pins, axles and bearings regularly to prevent premature failure of compo-
nents. (See Page 14 Section 1 for lubrication diagram).
NOTE: Maximum field operating SPEED OF the LAND ROLLER is 8 mph (13 km/h).
Above this speed damage can occur and will not be covered by warranty.
• Move tractor into position where pin can be dropped into place through draw bar hitch.
NOTE: Use a clevis type tractor hitch with a retained type of hitch pin.
• Retract parking jack and secure in transport position prior to moving the machine.
NOTE: Ensure that parking jack handle is secured by chain prior to moving the machine
(Failure to do so may damage the jack handle).
NOTE: Clean hydraulic hose ends prior to coupling with tractor hydraulic system.
• Ensure that the roller sections are either; Fully raised in transport position, or Fully lowered into
field position.
NOTE: If the Roller is in transport position, ensure that all lock pins are in place.
• Chock block all tires front and back before disconnecting from the tractor.
NOTE: Failure to properly block unit may result in damage or injury. Negative hitch
weight may result if tires are not blocked properly in position.
• Lower parking jack (s) into position, lowering until roller hitch is raised off of the tractor clevis.
NOTE: Ensure that the jack is placed on firm ground prior to un hooking.
• During field operation, always make turns so that the inside wing drum continues to rotate. Sharp
turns will increase the stress applied to the auto-fold system & inside wing drum and may cause
damage to the unit.
