27
1 203-6044 812 Spindle, Ø2-1/2” X 11-3/4” Long
2 200-6011 812 Hub (complete)
3 201-6016 Outer Cup LM2720
4 201-6017 Inner Cup 3720
5 202-6013 DC 17 Dust Cap
6 290-6013 Outer Bearing, 2790
7 290-6014 Inner Bearing, 3780
8 295-6016 SE 17 Seal
9 534-7816 1” Castle Nut, NF, Gr.5, Black
11 554-5303 1” Spindle Washer, Black
12 556-0614 3/16” x 1-3/4” Cotter Pin, Pltd.
13 120-1246 812 Hub & Spindle Assembly
14 543-5563 9/16” Wheel Nut, UNF
15 543-5564 9/16” Wheel Stud
