Fuses & OBD Connector Location
Fuses & OBD Connector Location
Open the front compartment and remove the
plastic bulkhead so you can access this area.
Open the front compartment and remove the
plastic bulkhead so you can access this area.
Fuses & OBD Connector Location
Fuses & OBD Connector Location
Open the seat and you will see the connector
close to the fuel tank.
Open the right side rear access panel to nd the
fuse box & OBD connector.
Step 5
Unplug MaptunerX from computer and plug the MaptunerX in to
the OBD connector on your vehicle (See Fig. 2 - 7).
