Figure4‐SamplePictureofAP‐6048HydraulicPumpwiththe
HydraulicPortpluggedfortesting(TopView)


Hydraulic
PressureGauge
HydraulicPressure
ControlKnob
RedReservoir
Ca
p

Hydraulic
PortPlug
Hydraulic
Port
AirPressure
Gauge
AirFilter‐
Regulator
HandSwitch
