Figure5–SamplePictureofMP‐6809HydraulicPumpwiththe
HydraulicPortpluggedfortesting(RightSide)






Figure6–SamplePictureofMP‐6809HydraulicPumpwiththe
HydraulicPortpluggedfortesting(LeftSide)
LeverArm
PressureGauge
H
y
draulicPort
FillerPlug
ReleaseKnob
FlexibleHose
HydraulicPortPlug
