2.0Scope

ThisdocumentdescribestheproperuseofaRiverhawkhydraulicpumpkit.

RiverhawkP/N GEVENDOCP/N Description
MP‐0130
MP‐6809
AP‐0532
AP‐6048
359B2506
373A4084
359B2502
269B8768
ManualHydraulicPumpKit
ManualHydraulicPumpKit
Air‐DrivenHydraulicPumpKit
Air‐DrivenHydraulicPumpKit

Thefiguresattheendofthismanualdepictthelocationofthecomponentsusedtooperatethe
hydraulicpumpkits.


3.0QuickChecklist

The following checklist isintended asa summaryof the steps needed to usethe Riverhawk‐
suppliedhydraulicpumpkits.Newpersonnelorthoseexperiencedpersonnelwhohavenotused
theRiverhawkequipmentrecentlyareencouragedtoreadtheentiremanual.

□
Checkoillevelinthehydraulicpump.(Refertosection6.2formoreinformation)
□
Fortheair‐drivenhydraulicpump,insurethatthepump’sairpressureissetbetween
80psi[5.5bar]to100psi[6.9bar].
□
Checkhydraulicpressuregageforanydamage.
□
Testthepumpbeforeconnectingthehydraulichoseortensioner.
ManualPump(Refertosection4.1.1formoreinformation)
AirDrivenPump(Refertosection4.1.2formoreinformation)
□
Checkhydraulichoseforanydamage.(Refertosection4.2formoreinformation)
□
Checkhosecollarsetting.(Refertosections4.2.1and4.2.2formoreinformation)
□
Checkcleanlinessofpumpportandhoseconnection.
□
Connectthehydraulicpumptothehydraulichose.
