Checkhydraulicpressuregageforanydamage.

Thepumpreservoircapissealedforshipment.Replacethegreyshippingplugwiththered
plasticreservoircap.

Asupplyofclean,dryairisrequired.Lubricatedairisnotrequired.

Attachthemaleairfittingstothepump’sairfilter‐regulator.Attachthefemaleairfittingtothe
airhose.

Coupletheairhosetotheairfilter‐regulatorandadjusttheairfilter‐regulatorknobuntiltheair
pressuregagereadsthepressurelevelmarkedonthepump.Formostair‐drivenpumps,theair
supplypressureshouldbesettowithintherangeof80psi[5.5bar]to100psi[6.9bar].

Reviewsection5.2foroperatinginstructionspriortotestingthepump.

Testpumpbydead‐heading(leaveportpluginplace)andactivatethepump.Thepressure
gaugeshouldbuildpressureandthenholdthesteadypressurewhenthepumpstops.

4.2CheckHydraulicHose

Checkthehydraulichoseforanydamageincludingbenthoseends,
kinkedhoseandsplitouter
lining.Ifanydamageisfound,replacethehoseimmediatelybycontactingRiverhawkCompany.

4.2.1The1/4”HighPressureFittingAssembly



Illustration1
TheRiverhawkhydraulichosemayusea1/4"High
PressureFittingtoconnecttoatensioner.The
hoseconnectorismadefromathreepiece
assembly:aglandnut,acollar,anda1/4”tubeor
1/4”hoseend.(SeeIllustration1)

Toassemblythefitting,slidetheglandnutover
the1/4”tubeor1/4”hoseend.Turnthecollar
counter‐clockwise(lefthandthread)ontothe
tubeorhoseendasshowninIllustration1.
