Illustration2
Thecollarshouldbeplaced.125”(3.2mm)from
thetipofthecone.(SeeIllustration2)Itmaybe
necessarytoadjustthiscollarwithasetofvise‐
grippliers.Becarefultonotstripthethreadsoff
thetubeorhoseend.





Illustration3
Slidetheglandnutdownoverthecollar.(See
Illustration3)Insertthe1/4”tubeor1/4”hose
endintotensionerorhydraulicpump.Whilefirmly
holdingthetubeorhoseendtostopitfrom
rotating,turntheglandnutclockwise(righthand
thread)andtorquetheglandnutto25FT‐LBS(34
N‐m).

Tips:
 Makesureallpartsarecleanandfreefrom
debris.
 Protecttheconeontheendofthe1/4”tube
or1/4”hoseendfromscratchesasthisisthe
sealingsurface.
 Replaceredplasticcapswhenfinishedto
protectthethreadsandcone.


