4.2.2The3/8”HighPressureFittingAssembly



Illustration4
TheRiverhawkhydraulichosemayusea3/8"High
PressureFittingtoconnecttoatensioner.The
hoseconnectorismadefromathreepiece
assembly:aglandnut,acollar,anda3/8”tubeor
3/8”hoseend.(SeeIllustration4)

Toassemblythefitting,slidetheglandnutover
the3/8”tubeor3/8”hoseend.Turnthecollar
counter‐clockwise(lefthandthread)ontothe
tubeorhoseendasshowninIllustration4.



Illustration5
Thecollarshouldbeplaced.250”(6.4mm)from
thetipofthecone.(SeeIllustration5)Itmaybe
necessarytoadjustthiscollarwithasetofvise‐
grippliers.Becarefultonotstripthethreadsoff
thetubeorhoseend.

