Page 2 of 4
AVON
Bedroom
Assembly Instructions
F-A
F-B
H-G
H-H
H-I
H-J
H-A
H-B
H-C
H-D
H-E
H-F
H-J
ASSEMBLY STEPS:
1. Place the Headboard Panel (H-A) face down on a soft surface such as a blanket or carpet.
2. Attach the Left and Right Legs (H-B) to the back of the Headboard Panel using the Allen-Head Bolts (H-D), Spring
Washers (H-E) and Flat Washers (H-F). Do not fully tighten Bolts until after next step.
3. Attach the Stretcher (H-C) to the Legs as shown using the Allen-Head Bolts (H-G), Spring Washers (H-H) and Flat
Washers (H-I). Do not fully tighten Bolts until after next step.
4. Adjust parts for correct fit if necessary and tighten all Bolts using the Allen Key (H-J).
5. Carefully lean the assembled Headboard against the wall where the bed will be used.
6. Install the bun feet onto the bottom footboard as shown.
Note: There are levelers installed in the bottom of the posts which can be adjusted if needed.
