6 Owner’s manual | Up adjustable bed
Installation guide
NOTE: For safety reasons, any lifting of the adjustable bed must always be performed by two (2) people. The
unit should be on a flat surface before opening.
Seing up your adjustable bed
With two people, carefully lift the bed base out of the shipping carton and place
it flat on the floor with the top side facing downward. Verify that all parts are
available before discarding any packing materials.
Unfold the base. Keep the top side facing down.
For all sizes.
1
2
Plug the input power cord into the power supply.
Connect the power supply to the head motor attached to the bed.
Connect the wired remote control to the head motor attached to the bed.
Slide a gasket over the bolt at the top of each bed leg. Attach the legs to the threaded
holes in each corner of the frame. Tighten until secure, but do not overtighten.
With two people, turn the bed over so that the legs are on the floor. Do not rest the
bed on the legs while flipping it over, as that can cause damage.
Make sure the cords do not interfere with operation of the bed. Plug the power cord
into a grounded electrical outlet. A surge protector (not included) is recommended.
Verify that the bed is operational by using each function on the remote. Then
return the bed to a flat position.
Insert the mattress retainer bar into the two holes at the foot end of the bed. Place
your mattress and bedding on top. Your adjustable bed is now ready to use.
3
4
5
6
7
8
9
6 Owner’s manual | Up adjustable bed
10
Input power cord and power supply
Connect cords to head motor
Attach legs to discs on the bed's frame
