RJS D4000 SP1 - Page 44

Appendix F Operator’s Guide
RJS, Minneapolis, MN 002-5572
38
Table F-2, (Parameters Checked for Each Symbology)
Symbology Ratio ICG Data
Character
Mod
Check
Tolerance
AIAG B-1 2.2-3.2 .5X-8X STD CODE 39 N/A ((12R-8)/81)X
AIAG B-3/4/5
2.8-3.2 .5X-8X
$/+%
Not Allowed N/A ((12R-8)/81)X
LOGMARS 2.2-3.0 .5X-8X STD CODE 39 N/A ((12R-8)/81)X
ANSI 3 of 9 2.2-3.0 .5X-8X STD CODE 39 N/A ((12R-8)/81)X
3 of 9 w/43 2.2-3.0 .5X-8X STD CODE 39
4 CHARS Min
MOD 43 ((12R-8)/81)X
HIBC 3 of 9 2.2-3.0 .5X-8X STD CODE 39
Min 2 CHARS
1ST. = "+"
MOD 43 ((12R-8)/81)X
ANSI 2 of 5 2.2-3.0 N/A N/A N/A ((18R-21)/80)X
Case Code 2.3-2.9 N/A 3 Data Chars
Min.
MOD 10 ((18R-21)/80)X
Code 128 N/A N/A N/A MOD 103 .35X
128 Case Code N/A N?A 16 Data Char.
Format Check
Mod 10
Mod 103
.35X
UPC/EAN N/A N/A N/A MOD 10
See Note
3
See Note 5
Codabar
Variant
2.2-3.0 .5X-8X STD
CODABAR
N/A ((5R-8)/20)X
Code 93 N/A N/A STD CODE 93 C&K .35X
