RMG 330 - 4.5 Spare Parts Drawing for Electric Remote Indication; 4.6 Spare Parts List for Electric Remote Indication

4.5 Spare parts drawing for electric remote indication
(not valid for SSV RMG 703/704)
Parts marked "W" are to be held in stock for maintenace purposes
673.20 p.11
4.6 Spare parts list for electric remote indication
320
321
322
323
324
325 W
326
327
328
329
330
331
item
no. description material RMG part no.
closing lid
spring guide
proximity switch
relais
spring
o-ring
metal ring
disc
Seeger ring
intermediate piece
cylindrical screw
spring housing
LM
LM
FSt
KG
St
St
FSt
LM
St
GLM
10 004 793
10 004 794
00 024 046
00 024 047
10 014 020
00 020 425
00 008 271
10 004 795
00 019 188
10 004 792
00 011 020
10 010 616
Parts marked "W" are to be held in stock for maintenace purposes
material key:
... steel
... spring steel
LM
GLM
... aluminium alloy
... cast aluminium
KG ... rubber-like plastic material
W
St
FSt
