RMG TME400-VCF User Manual

4 Operation
MANUAL TME400-VCF · EN08 · July, 01
st
2021
76
3
7N1
4
7E1
5
7O1
H03
RS-485 protocol
0
Off
1
Modbus RTU (default)
2
Modbus ASCII
H04
Modbus ID
Modbus device address (default = 1).
H05
Modbus register offset
The offset is defined as 1 by RMG.
Coor-
dinate
Name
Modbus
register
Modbus
access
Protec-
tion
Data
type
Min.
Max.
Default
Unit
H01
RS-485 Baud rate
709
W
N
menu16
0
3
3
Bps
H02
RS485 parameter
710
W
N
menu16
0
5
0
H03
RS485 protocol
711
W
N
menu16
0
2
1
H04
Modbus ID
712
W
N
uint16
1
250
1
MID
H05
Modbus register offset
713
W
N
uint16
0
10000
1
Mof
4.3.3.9.
Archive
Coordi-
nate
Name
Description
X01
Time
Direct entry of the current time as described above.
X02
Date
Direct entry of the current date as described above.
X10
Delete parameter ar-
chive
0
No (default)
1
Yes
X11
Param. archive fill level
Display value
X14
Delete event archive
0
No (default)
1
Yes
X15
Event archive fill level
Display value
X16,
X17,
X18,
X19,
X20,
X21,
X22,
X23
Measurement archive
mode
0
Off (default)
1
On
If measurement archive mode is activated, the following
archives are visible and can be adjusted and deleted as
necessary.
Minutes archive
X17 interval
0
15 minutes (default)
1
30 minutes
2
60 minutes
