Comprehensive list of monitor messages
• The “Status” light is solid green.
The system is ready for towing.
• The “Status light is flashing red and green.
The monitor isn’t receiving a signal from the towed vehi-
cle. Pump the towed vehicle’s brake pedal — the light should
now be solid green.
• The “Status” light is off.
The monitor “Power” switch has been turned off, or the
monitor has powered down.
• The “Status” light is yellow.
The towed vehicle’s battery is low.
• The “Status” light is flashing bright red; the “Brake”
light is flashing yellow; accompanied with an audible
alarm.
The towed vehicle’s brakes have been on continuously
for 30 seconds (for example, at a long stop light). Pump the
motorhome brakes to reset the 30 second timer.
Alternatively, press the “Silence” button once — the timer
will now alarm only after 60 seconds of continuous braking.
Motorhome monitor color code chart
Status Brake Breakaway
Light Light Light Color Description
•
solid green ........................... The system is ready for towing.
••
flashing red and green ........ The monitor isn’t receiving a signal from the transmitter.
•
“status” light is off ............... The “Power” switch has been turned off.
•
yellow .................................. The towed vehicle’s battery is low.
• •
flashing red and yellow ....... Extended braking alert
♪(includes an audio alert)
• •
solid red and flashing red ... A break away is in progress.
♪(includes an audio alert)
•
solid yellow .......................... The towed vehicle’s brakes are being applied.
continued from preceding page
How to pair the monitor and transmitter
The motorhome monitor and the towed vehicle transmit-
ter have been paired at the factory. If they’ve lost connectiv-
ity pair them as follows:
1. Power on the motorhome monitor.
2. Depress and hold the “Power” button on the motorhome
monitor for about five seconds. The “Status” light will flicker
yellow.
3. Release the “Power” button. The “Status” light on both
the towed vehicle transmitter and the motorhome monitor
will start flashing yellow. The units are now in pairing mode.
4. Depress and release the brake pedal in the towed vehi-
cle. The lights will stop flashing. The transmitter and monitor
are paired.
Monitor alerts
If the “Silence” button is pressed again after the alarm
at 60 seconds, it will reset the timer to only alarm after 90
seconds. This can be extended once more to 120 seconds.
Caution
If the monitor alerts you to extended braking when you
are not braking the motorhome, the brakes in the towed
vehicle are being applied inappropriately. Immediately
pull over and investigate to prevent brake damage.
• The “Status” light is flashing bright red; the “Break
away” light is solid red; accompanied with an audible
alarm.
The monitor is reporting a break away signal from the
towed vehicle. Pull over as soon as it is safe to do so and
investigate.
• The “Brake” light is yellow.
The “Brake” light will illuminate yellow whenever the
towed car’s brakes are on.
