Figure 1
Figure 2
Check the ICX transmitter.
The Even Brake circuit board will be destroyed if the ICX transmitter is
defective. To that end —
• If a new ICX transmitter is included, use it. Disconnect the old transmit-
ter, connect the new one and reprogram the monitor, as described in the
owner’s manual. (The most current version of the manual is available at
roadmasterinc.com.)
• If an ICX transmitter is not included, examine the
socket on the existing transmitter. A plastic protector
(Figure 1) must be in place. If it is not (Figure 2), DO
NOT USE THE TRANSMITTER! Doing so will destroy
the Even Brake circuit board.
Instead, call Roadmaster and order a replacement
ICX transmitter.
• When you connect Even Brake to the ICX transmit-
ter, the curved side of the plug (Figure 3) must align to
the curved side of the socket (Figure 1) on the trans-
mitter. If it does not, the Even Brake circuit board will be destroyed.
Time Tested • Time Proven
255294-00 09.14
Figure 3
Figure 1
Figure 2
Check the ICX transmitter.
The Even Brake circuit board will be destroyed if the ICX transmitter is
defective. To that end —
• If a new ICX transmitter is included, use it. Disconnect the old transmit-
ter, connect the new one and reprogram the monitor, as described in the
owner’s manual. (The most current version of the manual is available at
roadmasterinc.com.)
• If an ICX transmitter is not included, examine the
socket on the existing transmitter. A plastic protector
(Figure 1) must be in place. If it is not (Figure 2), DO
NOT USE THE TRANSMITTER! Doing so will destroy
the Even Brake circuit board.
Instead, call Roadmaster and order a replacement
ICX transmitter.
• When you connect Even Brake to the ICX transmit-
ter, the curved side of the plug (Figure 3) must align to
the curved side of the socket (Figure 1) on the trans-
mitter. If it does not, the Even Brake circuit board will be destroyed.
Time Tested • Time Proven
255294-00 09.14
Figure 3
