Monitor Panel
54
© 2014 by Roadtrek, Inc.
Battery Disconnect Inverter switch for standard 750 watt
inverter
Inverter switch for optional 2500 watt
inverter
Inverter
The inverter provides 120 volt AC (household current) to the 120 volt appliances and wall outlets. If you have the optional
engine generator and 2500 watt inverter, your inverter switch is back by the thermostat on the passenger side of the rear
lounge area. See the Optional Engine Generator and 2500 Watt Inverter portion of the Electrical System section for further
information.
