Electrical System
53
© 2015 by Roadtrek, Inc.
on the plug to indicate when shore power is sensed on the incoming connection.
Electrical Outlets
The outlets are powered either from the inverter or from shore power when connected. The outlets are protected by GFCI
(ground fault circuit interrupters).
There are two outlets on either side of the power sofa in the rear, and one near each of the second row captain's chairs. Each
have triple outlet panels with 120 volt, 12 volt and USB plugs.
These outlets can be switched on and off at both the distribution panel in the rear and the control panel in the front of the
Roadtrek. If you have no power at an outlet, check to make sure the rocker switch or touch screen is correctly positioned.
These outlets may have an ATC fuse built in. If the outlet is not working, have a technician check the fuse.
120 volt outlet 12 volt outlet
