Mounting
The key part of this controller is an universal one, especially rotary standard switch element that can be
integrated in numerous frames by different manufactures as below list:
BERKER S1, B1, B3, B7 glass
GIRA Standard55, E2, Event, Esprit
JUNG A500, Aplus
MERTEN M-smart, M-Arc, M-Plan
2.Install the controller to wall(2 methods)
Method 1:Stick 3M glue on the
back of the bracket and then stick
the bracket to the wall
Method 2:Screw the bracket
to the wall
After the bracket is fixed,clip
the frame and control part to the
bracket in sequence
① Use tool to open the
silicone gel battery cover
1.Remove battery insulator
②Pull out the
battery insulator
③Install the silicone
battery cover back
Installation
– leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or
the leakage of flammable liquid or gas;
liquid or gas.
- a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable
– disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in
Risk of explosion if the battery is replaced by an incorrect type
an explosion;
CAUTION
– replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some
lithium battery types);
