To determine the total wattage required to run a particular electrical appliance or tool, multiply the voltage
figure of the appliance/tool by the amperage (amps) figure of same. The voltage and amperage (amps)
information can be found on a name plate which is normally attached to electrical appliances and tools.
NOTE
The following wattage chart is general guide only. Refer to your specific appliance for
correct wattage.
Applications
Applicable Wattage (W)
RG4300iS
approx. 3800
approx. 1900
RG2800iS RG3200iS
approx. 1600
60Hz
approx. 800
Incandescent lamp, Heater approx. 2500 approx. 2800
Fluorescent lamp, Electric tool approx. 1300 approx. 1400
Mercury lamp approx. 800 approx. 1000
Pump, Compressor approx. 500 approx. 600
Nominal
cross
section
A.W.G.
Allowable
current
No.of strands
/ strands dia.
Resistance
Current Amp.
No./mm
Ω/100m
mm
2
No. A 1A 3A 5A 8A 10A 12A 15A
0.75 18 7 30/0.18 2.477 2.5V 8V 12.5V
─ ─ ─ ─
Voltage drop
1.27 16 12 50/0.16 1.486 1.5V 5V 7.5V 12V 15V 18V
─
2.0 14 17 37/0.26 0.952 1V 3V 5V 8V 10V 12V 15V
3.5 12 to 10 23 45/0.32 0.517
─
1.5V 2.5V 4V 5V 6.5V 7.5V
5.5 10 to 8 35 70/0.32 0.332
─
1V 2V 2.5V 3.5V 4V 5V
VOLTAGE DROP IN ELECTRIC EXTENSION CORDS
When a long electric extension cord is used to connect an appliance or tool to the generator, a certain
amount of voltage drop or loss occurs in the extension cord which reduces the effective voltage available for
the appliance or tool.
The chart below has been prepared to illustrate the approximate voltage loss when an extension cord of 300 feet
(approx. 100 meters) is used to connect an appliance or tool to the generator.
