Robinsons Rowton - Page 12

12
Part No mm Quantity
D048 1676 2
D057 1830 2
D1130 1366 1
D1131 714 1
D1132 714 1
D1141 1703 2
Part No mm Quantity
D174 4
M6X10 8
M6X15 10
M6NUT 18
D111 1
D227 15.5m
D1130
D057
D057
D048
D048
D1132
D1141
D1141
D1131
10mm
15mm
15mm
15mm
15mm
10mm
15mm
15mm
15mm
15mm
10mm
10mm
10mm
10mm
15mm
15mm
15mm
15mm
You may
wish to
pre-load
the rear
glazing bars ‘D057’
with square head
10mm bolts for any
2’ shelves pur-
chased rather than
use crop heads
retrospectively.
