Example: 3 x 2’ 3 slat shelves in rear gable
D2021
15mm
10mm
crop
10mm
10mm
D2013
D2014
crop
10mm
D2001
=620mm
Part No Length
(mm)
Quantity
D2001 620
3
D2013 285
2
D2014 370
2
D2021 N/A
6
1 x 2’ 3 SLAT QUANTITIES
SYBOLM6
X11
10mm
8
SYBOLM6
X15
15mm
2
SYNUTM6 M6 nut
10
SYBOLM6
X11CROP
10mm
4?
IMPORTANT:
Please make sure when deciding
on your shelving heights that the
louvre handle or optional auto
louvre mechanism does not inter-
fere with the staging slats.
