3. Example of Mini-movement of a CoDrone
with Rokit Brick.
take-off Pitch (forward) 1.5 sec Roll( Left movement) 1.5 sec Landing
29
Take-Off
order
Peach 50%
1.5 sec
Roll 50%
1.5 sec
Landing
1.5 s movement in forward direction (pitch)
Clear the forward direction output (pitch) to zero
Move left (-roll) for 1.5 seconds.
Clear left-hand output (roll) to zero
* Different time or pitch output values can be used to adjust the
travel distance.
When you click on the green flag button, the drone takes off,
moves forward, and then moves on.
I want you to fly sideways (left)
