Whenever replacing the blades, it is recommended to restart the counter of the blades replacement
reminder by choosing the ‘Blades replaced’ option under the ‘User Preferences’ menu and press the GO
button again to clear the reminder.
Figure 8.1
S
q
ueeze tabs &
p
ull S
q
ueeze tabs &
p
ull
To remove blades, squeeze locking tabs on each side of blade retainer,
then pull blade assembly off, away from mower. When reinstalling the
blade, line up the mating splines and push until a firm click is heard,
indicating a proper seating of the blade onto the shaft.
Squeeze here
Locking tabs
Mating spline
Figure 8.2
CAUTION! ALWAYS REMOVE
POWER PACK BEFORE
SERVICING BLADES!
Squeeze here
49
Using a wooden stick or similar object, clean accumulated grass from these
areas of the mowing deck. Remove blades if necessary for better access.
