.2 Expanding and Folding of the Electric Wheelchair
Remarks: Before folding the electric wheelchair, empty the items
in the storage basket to prevent damage.
1
1
2
2
Figure 4.2.1.1
Figure 4.2.1.2
Expanding operation mode: When manually expanding the electric wheelchair, please press the
folding switch with one hand (position 1 in Figure 4.2.1.1) and pull the armrest up with the other hand
(position 2 in Figure 4.2.1.1) until the electric wheelchair is fully expanded;
Folding operation mode: When manually folding the electric wheelchair, please press the folding
switch with one hand (position 1 in Figure 4.2.1.2) and pull the armrest up with the other hand (position
2 in Figure 4.2.1.2) until the electric wheelchair is fully folded;
4
.2.1 Expanding and Folding Operation Mode
4
. Using the electric wheelchair
