35
(2)In Step 2, manually rotate the right knob of the battery case and rotate the right
knob to the unlocking position. Then open the battery right buckle. (As shown on
Figure 4.6.1.1.2)
Figure 4.6.1.1.2
3
4
(3)In Step 3, remove the battery in the direction shown in the figure. (As shown on
Figure 4.6.1.1.3)
Figure 4.6.1..1.3
5
4.Use of the Electric Wheelchair
