39
4.7 Switch to pushing mode
press at the same
time
Press '︿' key and '﹀' key at the same time to enter pushing mode. Shake the joystick
can exit the pushing mode;( As shown on Figure 4.7)
Figure 4.7
4.8 Electric Wheelchair charging mode
Charging method II: Take out the
battery, plug the charger plug into
the charging port of the battery to
charge;( As shown on Figure 4.8.2)
Figure 4.8.1 Figure 4.8.2
Charging method I: Connect the
charger and plug the charger plug
into the upper controller for
charging;( As shown on Figure 4.8.1)
4.Use of the Electric Wheelchair
To Next Page
