38
Model
Rated output current
Rated output voltage
Operating Temperature Range
Battery charger environmental protection class
Battery Model
Battery Rated Capacity
HP1211L2
4A
24V
-40C to 80°C
class VI
LY-BT-09/10
20AH/25AH
Table 4.6.2.1.1
Do not use the charger and AC connector cord other than those provided
with the device. Using a charger or AC connector cord other than the one
supplied may result in electric shock, or in burns caused by charger
overheating. In addition, do not use the charger and AC connector cord
included with the device in any other device.
4.6.2.1 Basic information
4.6.2.2 Charger indicator displays
4.6.2.3
The charger indicator illuminates or flashes according to the battery states
as shown below:
Red Light means charging.
Green light means full charger or disconnect.
The device cannot be used while the battery is being charged.
The approximate charging time is 8 hours.
The charger is designed to prevent overcharging. Even if the charger is left
plugged in for more than 8 hours, there is no risk of the device being
damaged. However for safety reasons, avoid leaving the charger plugged
into the wall outlet for a long time.
Immediately disconnect the DC connector from the battery after charging is
completed.
If the usable time after charging has become abnormally short and the
battery must be replaced, contact your distributor or customer support.
4.Use of the Electric Wheelchair
