37
（3）In Step 3, manually close the battery left buckle and rotate the left knob of the
battery box with the left knob to the locked position. (As shown on Figure 4.6.1.2.3)
Figure 4.6.1.2.3
4
5
4.6.2 User manual for battery charger：
Attention
Users should read the instructions before attempting to use the battery
charger.
The battery charger is intended for indoor use and is not to be exposed to
rain or other sources of moisture (unless the environmental protection
rating of the battery charger is at least IPX4).
Explosive gasses can be generated while charging, so the wheelchair and
battery charger are to be kept away from sources of ignition, such as flames
and sparks.
Charging is carried out with the wheelchair in a space at least twice its
volume, with sufficient ventilation that there is no hazard due to build-up of
flammable gas.
Only batteries of the specified type and capacity are to be charged.
Off-board battery chargers are not to be carried on wheelchairs.
Do not charge the battery while the brakes are released. There is a risk that
the device may move, causing an accident.
4.Use of the Electric Wheelchair
