meArm Assembly Manual v0.4

10ea - M3 Nut

4ea - M3 x 20

7ea - M3 x 12

5ea - M3 x 10

10ea - M3 x 8

9ea - M3 x 6

Fasteners:

Here are a list of fasteners required to build the meArm v0.4. The profiles below are actual size.

Note: The Servo Screws and Servo Mount Screws reference in the assembly manual are included with

the servos and do not need to be purchased seperately.
