Robot Coupe R2 B - Page 18

robot coupe U.S.A., Inc.
R2N Ultra
Serial number 231xxxxx03
247xxxxx03 500xxxxx03
1-Speed, 120 Volt, 1 Phase
60Hz, 1 HP, 1725RPM, 7 Amps
REV : c Maj: 06/2008
22 229
Index Pièce / Part Description
1
27 243 CUTTER ATTACHMENT
2
105 236 CUTTER LID
3
27 055 STRAIGHT BLADE
4
27 061 FINE SERRATED BLADE
5
39 795 CUTTER BOWL ASSEMBLY
7
100 964 SPRING
9
29 184 LOCKING PLATES ASSEMBLY
10
104 098 PLASTIC SAFETY ROD FOR BOWL H = 109m TYPE 1 3 QT
11
104 050 STAINLESS STEEL NUT FOR BOWL H = 109m TYPE 1 3 QT
12
39 109 MOTOR SUPPORT ASSEMBLY
13
501 010 SHAFT SEAL
16
39 107 CONTROL PANEL ASSEMBLY
17
407 670 FRONT PLATE
18
101 103 BOLT COVER
19
101 106 POWER CORD CLIP
20
200 005 SCREW 3,9 x 19
21
27 242 VEGETABLE SLICER ASSEMBLY
22
39 104 LID + PUSHERS ASSEMBLY
23
103 281 ROUND PUSHER
24
103 280 VEGETABLE PUSHER
25
118 592 VEGETABLE SLICER LID
26
29 858 GREY VEGETABLE SLICER BOWL SAFETY ROD ASSEMBLY
27
103 288 SLINGER PLATE
28
102 699 VEGETABLE SLICER BOWL ASSEMBLY
29
104 124 BASE
30
29 919 MICROSWITCH ASSEMBLY
31
500 527 SEAL RING
32
200 003 SCREW 3,5 x 12,7
33
101 096 VENTILATION BAFFLE
34
101 095 ABSORBER
35
39 865 BASE ASSEMBLY
36
39 928 FOOT ASSEMBLY (x4)
38
39 763 BOWL HANDLE ASSEMBLY
39
39 753 LOCKING WASHER ASSEMBLY
40
39 762 SAFETY ROD ASSEMBLY FOR BOWL TYPE 3
41
104 122 VENT COVER
42
101 098 VENT COVER + RIVETS
43
27 138 SERRATED BLADE
44
117 058 BLADE CAP
45
39 220 SAFETY ROD ASSEMBLY FOR BOWL H = 117m TYPE 2 3 QT
46
R286 CIRCUIT-BREAKER
47
R255 PLATE RACK
48
502 579 HONING STONE
49
R277A SCREEN KIT
50
29 007 WHITE VEGETABLE SLICER BOWL SAFETY ROD ASSEMBLY
51
R240 POWER CORD
52
R239 MOTOR AO SMITH
53
R239D.3 ADAPTER PLATE FOR EMERSON MOTOR
54
R239D MOTOR EMERSON
55
R222 CAPACITOR F/C MOTOR (R2N)
56
R237 BEARING 6203 AO SMITH MOTOR
57
R239D.2 CAPACITOR
58
RV30247 BEARING 6203 EMERSON MOTOR
59
R239D.1 STARTING RELAY EMERSON
