All material and assembly guide can de downloaded from WWW.ROBOTICSCITY.COM Pages Password : r2d2
Note: Experiments are updated constantly with new sample programs, references and new sensors reviews.
Sensors and CPU
Arduino Uno R3 Arduino UNO R3 computer board with DC-DC converter 1
USB Programming Cable USB Programming Cable 1
Arduino Sensor Shield V5.0 sensor shield to connect sensors, motors, LEDs 1
Micro Servo (blue colors) with screws Micro Servo (blue colors) with screws 1
Sonar Sensor holder and screw Sonar Sensor holder - spacer-glue and screws 1
Sonar Sensor HC-SR04
Sonar Sensor HC-SR04 1
360 Rotation Wheels Servo Motors
360 Rotation Wheels Servo Motors 2
Funduino Line Following Sensor Funduino Line Following 3 IR Sensors 1
GY-521 MPU-6050 3-Axis 6DOF gyroscope + accelerometer board GY-521 MPU-6050 3-Axis 6DOF gyroscope + accelerometer board
1
6 AA Battery Holder + on-off switch+cables 6 AA Battery Holder + on-off switch+cables 1
10K potentiometer 10K potentiometer 1
IR Remote Control with RX/TX+TX LED+cables IR Remote Control with RX/TX+TX LED+cables 1
CDS light analog sensor CDS light analog sensor 1
IR adjustable Distance Sensors IR adjustable Distance Sensors 2
Tactile momentary ON switches
Tactile momentary ON switches 2
1 kΩ Resistors 1 kΩ Resistors 2
10 kΩ Resistors 10 kΩ Resistors 4
220 Ω Resistors 220 Ω Resistors 8
Piezospeaker Piezospeaker 1
Feelers (momentary ON, long switches) Feelers (momentary ON, long switches) 2
Bluetooth HC05 or HC06 passcode 1234 Bluetooth HC05 or HC06 passcode 1234 1
DC-DC step down converter DC-DC step down converter 1
Bonus Sensor Humidity analog sensor 1
Upper Deck Chassis lasercut upper deck chassis 1
Lower Deck Chassis lasercutlower deck chassis 1
Wheels Servo Holder lasercut servo holder for wheels 2
Servo metal L Brackets servo metal L brackets 4
Wheels+screws Wheels+screws 2
4-40 X1/2" pan head screws for servos, front acorn, line IR 4-40 X1/2" pan head screws for servos, front acorn, line IR
13
4-40x1" flathead or panhead Screw for line following sensor 4-40x1" flathead or panhead Screw for line following sensor
2
4-40 X3/8" screws for L brackets and spacers 4-40 X3/8" screws for L brackets and spacers 8
4-40 X1/4" pan head screws 4-40 X1/4" screws for upper deck, Arduino 10
Nylon Spacers 4-40 Nylon Spacers 4-40 to mount Arduino 3
4-40x3/4 Screws
4-40x3/4" Screws feelers/switches 4
4-40x3/4" flathead Screw for back of battery pack 4-40x3/4" flathead Screw for back of battery pack
1
4-40 Metal Hex Nut 4-40 Metal Hex Nut 23
4-40 plastic nuts for IR sensors
4-40 plastic nuts for IR sensors 2
4-40 Acorn Nuts 4-40 Acorn Nuts 2
4-40x1.5 Hex Aluminum Spacers 4-40x1.5" Hex Aluminum Spacers 4
Dupont Wires Male/Male Dupont Wires M/M 8
Dupont Wires Female/Female Dupont Wires F/F 15
Dupont Wires Male/Female Dupont Wires M/F 8
Breadboard - 400 tie points
Breadboard - 400 tie points 1
4-40x1" Screw for breadboard and line following sensor 4-40x1" Screw for breadboard and mount line following sens
3
Screwdrivers mini flat and/or star Screwdriver mini flat and/or star 2
Sumo lasercut ramp Sumo lasercut ramp 1
Plastic L braket for sumo ramp Plastic L brakets for sumo ramp 2
Robot Container ship box , sticker, flyer Robot Container ship box , sticker, flyer 1
Electronics 101 parts - for the extra 10 experiments See http://www.roboticscity.com/electronics101.html
DC 5v motor 3-6VDC motor 1
Diode 1Nxxxx Diode 1Nxxxx 1
Extra LEDS
Extra LEDS - various colors 4
2N2222 or 2N3904 Transistor - please check before connecting 2N2222 or 2N3904 Transistor - please check before connecting
1
74HC595N shift register 74HC595N shift register 1
