User, Installation and Service Manual for F1 Gas Unit Heaters 23
Ed. 11/2006
P programmatore
TA termostato ambiente
RL relè comando
programmato
50 Hz
230 V
Figure 22
WIRING DIAGRAM FOR MULTIPLE HEATERS INSTALLATION WITH ONE PROGRAMMER AND ONE ROOM THERMOSTATS (ONE RELAY
SOLUTION)
P Programmer
TA ambient thermostat
RL programming relay
GND
