GB
11
앬 Never use a faulty or damaged electrical
equipment (this also applies to extension cables
and plug connections).
2. Layout (Fig. 1-4)
1 Tank indicator
2 Tank cover
3 2 x 230 V~ socket-outlets
4 Earth connection
5 Safety tripping element
6 Voltmeter
7 Oil filler plug
8 Oil drain plug
9 Oil shortage cut-out
10 On/Off switch
11 Choke lever
12 Reversing starter
13 Petrol cock
3. Proper use
The device is designed for applications operated with
a 230 V alternating current source. Be sure to
observe the restrictions in the safety instructions.
The generator is intended to provide electric tools
and light sources with electricity.
When using the device with household appliances,
please check their suitability in accordance with the
relevant manufacturer’s instructions. In case of
doubt, ask an authorized dealer of the respective
appliance.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Generator Synchronous
Protection type: IP23M
Continuous rated power P
rated
(S1): 2000 W
Maximum power P
max
(S2 2 min): 2200 W
Rated voltage U
rated
: 2 x 230V~
Rated current I
rated
:9 A
Frequency F
rated
: 50 Hz
Drive engine design: 4-stroke, air-cooled
Displacement: 196 cm³
Max. power: 4 kW / 5,4 hp
Fuel: petrol
Tank capacity: 13 l
Engine oil: approx. 0.6 l (15W40)
Consumption at 2/3 load: approx. 1.18 l/h
Weight: 31,5 kg
Sound pressure level L
pA
: 75 dB(A)
Sound power level L
WA
/Uncertainty K:
95 dB (A)/3 dB(A)
Power factor cos ϕ: 1
Power class: G1
Max. temperature: 40°C
Max. altitude (above mean sea level): 1000 m
Spark plug: NGK F6TC/F7TC
Operating mode S1 (continuous operation)
The machine can be continuously operated with the
quoted power output.
Operating mode S2 (temporary operation)
The machine may be temporarily operated with the
quoted power output (2 min).
5. Before putting the machine into
operation
5.1 Electrical safety:
앬 Electric supply cables and connected equipment
must be in perfect condition.
앬 The generator is to be operated only with
equipment whose voltage specifications conform
with the generator's output voltage.
앬 Never connect the generator to the power supply
(socket-outlet).
앬 Keep the cable length to the consumer as short
as possible.
